IP65 Radio Frequency Rotary Joint integrated power with SMA connector

IP65 Radio Frequency Rotary Joint integrated power with SMA connector

  • IP65 Radio Frequency Rotary Joint integrated power with SMA connector
  • IP65 Radio Frequency Rotary Joint integrated power with SMA connector
IP65 Radio Frequency Rotary Joint integrated power with SMA connector
Product Details:
Place of Origin: China
Brand Name: CENO
Certification: ISO9001,CE,RoHS
Model Number: ECN000-05P2-05S-04R
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Carton
Delivery Time: 1 week
Payment Terms: T/T,Paypal,, Western Union
Supply Ability: 500pcs per month
Contact Now
Detailed Product Description
Channel Number: 4 Frequency: DC To 900MHz
Interface Type: SMA Body Material: Aluminium Alloy +stainless Steel
IP Grade: IP65 Rotating Speed: 0~60 Rpm
Contact Material: Precious Metal Insertion Loss: <0.4 DB
High Light:

IP65 Radio Frequency Rotary Joint

,

SMA Radio Frequency Rotary Joint

,

IP65 rf slip ring

Stable transmission radio frequency rotary joint slip ring integrated power,with SMA connector used for radar antennas,high definition network and satellite communication.







CENO uses import high elastic wear-resisting material in the internal key contact point of the RF rotary joint and do special plating in the surface for it.It is a connector device to transmit high frequence signal from the static to rotating part.ECN000-05P2-05S-04R integrates current,signal & 4 channel RF rotating joints together for the radar industry.Its current can reach up to serveral hundred amps,the signal type could cover all types accoridng the application need,the frequency of high-frequency joints is from DC to 50Ghz,and the the channel could up to five channels.Any special requirements pelase contact with CENO team ,we will provide you with the best solution.











Specfication:





ECN000-05P2-05S-04R                      Specification
Circuits 4*10A,4*1A,4*RF
Voltage 0-440VAC/VDC
Electrical noise ≤30mΩ(50rpm)
Dielectric strength

≥1000V@50Hz (power)

≥300V@50Hz (signal)

Insulation resistance

≥500MΩ@500VDC (power)

≥100MΩ@100VDC (signal)

Operating speed 0~60 rpm
Contact material Precious metal
Housing material Aluminium alloy +stainless steel
IP protection grade IP65
Interface type SMA -f connector
Frequency range DC to 900MHz
Insertion loss <0.4 dB
VSWR <0.1











Features

  • Anti-interference ability
  • Compact structure
  • Stable transmission
  • 4 channels RF joints









Applications

  • High definition network
  • Satellite communication
  • Military industry
  • Radar antennas









Optional

  • Circuits number
  • Frequency range
  • Interface type
  • IP protection grade











Outline Drawing:



IP65 Radio Frequency Rotary Joint integrated power with SMA connector 0























Why with CENO

CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.

IP65 Radio Frequency Rotary Joint integrated power with SMA connector 1



Certification

ISO9001,CE,RoHS,UL,Explosion-proof



CENO Advantage

Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.



Service CENO provides

24 hours,7days consultant service.

Mass and customized production.

Solution offerring for 360° rotation system.



Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
