| Place of Origin: | China |
| Brand Name: | CENO |
| Certification: | CE,RoHS,UL,ISO9001 |
| Model Number: | ACN25J-04P1-30P-01HD-01EG |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton |
| Delivery Time: | Off the shelf |
| Payment Terms: | T/T,Paypal,Western Union, L/C |
| Supply Ability: | 10000pcs month |
| Circuit Number & Current: | 30*2A, 4*5A, 1*SDI; 1*Gigabit Ethernet | Voltage: | 0~110VAC/DC |
|---|---|---|---|
| Dielectric Strength: | ≥200VAC@50Hz ≥100VAC@50Hz | Isolation Resistance: | ≥50MΩ@200VDC ≥10MΩ@100VDC |
| Dynamic Resistance: | ≤35mΩ | Operating Speed: | 0~200rpm |
| Contact Material: | Gold To Gold | Housing Material: | Engineering Plastics |
| Working Temperature: | -20°C~+60°C | IP Protection Grade: | IP40 |
| Working Humidity: | 60% | Lead Wire Size: | AWG28# 22# Wire Teflon® UL CAT5e, RG178 |
| Lead Wire Length: | Rotor : 1000/650 ±5mm Stator : 1000/650 ±5mm | ||
| High Light: | High Definition HDMI Slip Ring,1000M Ethernet HDMI Slip Ring,1000M Gigabit Capsule Slip Ring |
||
HDMI High Definition Slip Ring With Capsule & 1000M Gigabit Ethernet Signal
ACN25J-04P1-30P-01HD-01EG is a capsule slip ring which combined 35 circuits for electric power, 1 circuit for SDI and 1 circuit for 1000M Gigabit Ethernet signal from CENO Electronics. And most of the parameters are optional, such as 1 to 200 circuits, Protect grade IP40 to IP68 and temperature -55 to 250°C can be designed as different working environment. The capsule slip ring has compact structure and especial suit for the small rotation system and often transmit weakness control signals. Mainly apply to the Traffic system, Video monitoring system, Drones and Process control system. If this slip ring isn’t quite what you’re looking for, we’ve got you covered.
Features
Applications
Optional
Specification
|
ACN25J-04P1-30P-01HD-01EG |
Specification |
| Current & Circuits |
30*2A; 4*5A; 1*SDI; 1*Gigabit Ethernet |
| Rating Voltage |
0~110 VAC/VDC |
| Dielectric strength |
≥200VAC@50Hz |
| Isolation resistance |
≥50MΩ@200VDC |
| Dynamic resistance | ≤35mΩ |
| Operating speed | 0~200rpm |
| Contact material | Gold to gold |
| Housing material | Engineering plastics |
| Working temperature | -20°C~+60°C |
| IP protection grade | IP40 |
| Working Humidity | 60% |
| Lead Wire Size |
AWG28# 22# Wire Teflon® UL |
| Lead wire length |
Rotor : 1000/650 ±5mm |
Outline drawing
Our Service
1. Reply inquiry in 24 hours.
2. Please kindly inform us which items you are interested & the reasonable price will be provided you upon receipt of your new inquiry ASAP.
3. Answer your question detailed.
4. Solved the problem with you during using our products.
5. Samples will be offered to you for our future cooperation.
FAQ
1. What do we do?
We focus on developing, designing, manufacturing high quality sliprings, and offer various solutions for rotating systems.
2. How long have we been in the business?
CENO established slip rings business since 2009. We have thousands of customers accepted our products or services.
3. What is a slip ring?
A slip ring is an electromechanical device that allows the transmission of power and electrical signals from a stationary to a rotating structure. A slip ring can be used in any electromechanical system that requires rotation while transmitting power or signals. It can improve mechanical performance, simplify system operation and eliminate damage-prone wires dangling from movable joints.
4. How do I choose a slip ring?
Proper selection of a slip ring solution requires details about your application’s operating parameters including total circuits, voltage and amps per circuit, operating speed, and mounting type. A good place to start your search is with our standard slip rings. If you are confident that a custom / modified solution is most likely required or need assistance in your selection, contact us to Get Started.
5. Do you offer custom slip rings?
Yes, if you are confident that a custom / modified solution is most likely required or need assistance in your selection, contact us to Get Started. Our engineers will come up with perfect solution for your needs.
