Place of Origin: | China |
Brand Name: | CENO |
Certification: | ISO9001,CE,RoHS |
Model Number: | QCN0204-16P1-16S |
Minimum Order Quantity: | 1pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Carton |
Delivery Time: | 2 weeks |
Payment Terms: | T/T,Paypal, Western Union |
Supply Ability: | 1000pcs per month |
Current & Circuits: | 16*5A, 4*Profi-net Signal | Rating Voltage: | 0~220VAC/VDC |
---|---|---|---|
Dielectric Strength: | ≥500V@50Hz | Isolation Resistance: | ≥300MΩ@100VDC |
Contact Resistance: | ≤30mΩ | Operating Speed: | 0~50rpm |
Contact Material: | Precious Metal | Housing Material: | Aluminum Alloy + Stainless Steel |
Working Temperature: | -20°C~+80°C | Working Humidity: | 60 %RH |
IP Protection Grade: | IP65 | Lead Wire Size: | 4 Cores Cable 4 Cores Two Twisted Shield Cable |
Lead Wire Length: | Rotor : 1000mm Stator : 1000mm | Channel: | 2 Channel * Gas |
Connect Inch: | RC 1/8” | Operation Pressure: | 1.0MPa |
Rotary Torque: | ≤3N*m | ||
High Light: | Pneumatic Rotary Union Integrated Slip Ring,50rpm Integrated Slip Ring,220VAC Integrated Slip Ring |
Integrated Slip Ring with Pneumatic Rotary Union For Automotive Industry
QCN0204-16P1-16S is a integrated slip ring which combined electric power, profi-net signal and pneumatic for industry application from CENO Electronics. The boundary dimension, installation and sealing form can be selected according to different application. The electric circuits can be up to hundreds, and the pneumatic or hydraulic can reach to 16 channels as different environment.It’s often apply to the Medical equipment, Filling machine, Plastic fiber manufacture or iron and steel industry. For more information about how CENO’s slip ring can fit your specific application, please contact us freely
Features
Integrated profi-net signal pneumatic and electric power
Install easily & transmit stably
Protection grade IP65
Parameters are optional
Applications
Automatic machine
Laser cutting machinery
Iron & steel industry
Plastic fiber manufacture
Filling machine
Optional
Circuit number & Current
Pneumatic & Hydraulic channel
Materials
Protection grade
Working speed
Specification
QCN0204-16P1-16S |
Specification |
Current & Circuits | 16 circuits * 5A, 4 group * Profi-net Signal |
Rating Voltage | 0~220VAC/VDC |
Dielectric strength | ≥500V@50Hz |
Isolation resistance | ≥300MΩ@100VDC |
Contact resistance | ≤30mΩ |
Operating speed | 0~50rpm |
Contact material | Precious Metal |
Housing material | Aluminum Alloy + Stainless steel |
Working temperature | -20°C~+80°C |
Working humidity | 60 %RH |
IP protection grade | IP65 |
Lead wire size |
4 cores cable 4 cores two twisted shield cable |
Lead wire length |
Rotor : 1000mm Stator : 1000mm |
Air | Parameter |
Channel | 2circuits * gas |
Connect inch | RC 1/8” |
Air pressure | 1.0MPa |
Rotary Torque | ≤3N*m |
Outline Drawing
Our Service
1. Reply inquiry in 24 hours.
2. Please kindly inform us which items you are interested & the reasonable price will be provided you upon receipt of your new inquiry ASAP.
3. Answer your question detailed.
4. Solved the problem with you during using our products.
5. Samples will be offered to you for our future cooperation.
FAQ
1. What do we do?
We focus on developing, designing, manufacturing high quality sliprings, and offer various solutions for rotating systems.
2. How long have we been in the business?
CENO established slip rings business since 2009. We have thousands of customers accepted our products or services.
3. What is a slip ring?
A slip ring is an electromechanical device that allows the transmission of power and electrical signals from a stationary to a rotating structure. A slip ring can be used in any electromechanical system that requires rotation while transmitting power or signals. It can improve mechanical performance, simplify system operation and eliminate damage-prone wires dangling from movable joints.
4. How do I choose a slip ring?
Proper selection of a slip ring solution requires details about your application’s operating parameters including total circuits, voltage and amps per circuit, operating speed, and mounting type. A good place to start your search is with our standard slip rings. If you are confident that a custom / modified solution is most likely required or need assistance in your selection, contact us to Get Started.
5. Do you offer custom slip rings?
Yes, if you are confident that a custom / modified solution is most likely required or need assistance in your selection, contact us to Get Started. Our engineers will come up with perfect solution for your needs.
Why with CENO
CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.
Certification
ISO9001,CE,RoHS,UL,Explosion-proof
CENO Advantage
Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.
Service CENO provides
24 hours,7days consultant service.
Mass and customized production.
Solution offerring for 360° rotation system.
Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
