| Place of Origin: | China |
| Brand Name: | CENO |
| Certification: | CE,RoHS,UL,ISO9001 |
| Model Number: | ECN000-01S-600 |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton |
| Delivery Time: | Off the shelf |
| Payment Terms: | T/T,Paypal,Western Union, L/C |
| Supply Ability: | 10000pcs month |
| Rating Voltage: | 240VAC | Dielectric Strength: | ≥500VAC@50Hz |
|---|---|---|---|
| Working Temperature: | -20°C~+60°C | IP Protection Grade: | IP54 |
| Working Humidity: | 60%RH | Installation: | Rotor Side Fixed On Guest Main Shaft |
| Operating Speed: | 0~600rpm | Lead Wire Length: | Rotor : 100mm + SMA Connector Stator : 250mm+BNC Connector Shielded Wire : 300mm |
| Current & Circuits: | 1* HD Signal; 1*Fiber(guest Supply ); 1*shielded Wire | Isolation Resistance: | ≥100MΩ@100VDC |
| Contact Resistance: | ≤50mΩ (50rpm) | Contact Material: | Precious Metal |
| Housing Material: | Aluminum Alloy | External Diameter: | Ø90mm |
| High Light: | HDMI Signal Fiber Optic Slip Ring,240VAC Fiber Optic Slip Ring,90mm Fiber Optic Slip Ring |
||
Our HDMI Slip Ring is a customized slip ring for HDMI signal transmission. It is designed to provide a reliable rotation while transferring data signal with low noise. This slip ring has an external diameter of Ø90mm and a rotor lead wire length of 100mm+SMA Connector and stator lead wire length of 250mm+BNC Connector, Shielded Wire of 300mm. It has an IP protection grade of IP54 and a rating voltage of 240VAC, and can be used in working humidity of 60%RH.
Our HDMI Slip Ring is perfect for any application where HDMI signal needs to be transferred while the slip ring rotates. It features high-density signal transmission, low noise, high reliability and stability, and high wear resistance. Our HDMI slip ring has been tested and approved for use in extreme temperature, humidity, and vibration environments.
| Name | Value |
|---|---|
| Installation | Rotor Side Fixed On Guest Main Shaft |
| Isolation resistance | ≥100MΩ@100VDC |
| Operating speed | 0~600rpm |
| External diameter | Ø90mm |
| Dielectric strength | ≥500VAC@50Hz |
| Working temperature | -20°C~+60°C |
| Rating Voltage | 240VAC |
| Working humidity | 60%RH |
| Contact material | Precious Metal |
| IP protection grade | IP54 |
| HDMI Signal slip ring | Integrated slip ring |
CENO ECN000-01S-600 Rotary HDMI Signal Joint is designed for the applications that require high speed signal transfer with continuous 360° rotation. This slip ring has 1* HD Signal, 1*Fiber(guest Supply ) and 1*shielded Wire circuits, and provides IP54 protection and 500VAC insulation.
The working temperature of this slip ring is -20°C~+60°C, so it can be used in different environments. The rotor side of this slip ring is fixed on the guest main shaft, making it easy to install. Moreover, this slip ring is a customized product, and it can be tailored to fit your specific requirements.
With the help of CENO ECN000-01S-600 Rotary HDMI Signal Joint, you can easily transmit high speed signals and data reliably and stably even in the rotating motion. If you are looking for a Fiber Optic Rotary Joint, this is the perfect choice.
We provide technical support and service for our customers who have purchased our HDMI Slip Ring. Our team is experienced and knowledgeable in the installation, maintenance, and troubleshooting of this product.
We provide detailed installation instructions and diagrams for our HDMI Slip Ring. Our team is also available to answer any questions or provide assistance during the installation process.
We provide regular maintenance services for our customers. Our team will inspect the HDMI Slip Ring to ensure that it is working correctly and efficiently.
Our team is available to answer any questions or provide assistance in troubleshooting any issues with the HDMI Slip Ring. We provide detailed instructions for troubleshooting any problems with the product.
HDMI Slip Rings Packaging and Shipping:
Contact Person: Lam
Tel: +8615767660191
