Protection Grade IP67 Water proof Slip Ring with Miniature Capsule
ACN22-04P-06S-IP67 is CENO new function slip ring capsule with protection grade IP67 and can be up to IP68 for special request. There are kinds of function slip ring at CENO, such as the Anti-explosion slip ring, high / low temperature slip ring, high speed slip ring and waterproof slip ring. The water proof slip ring used in environments such as humidity, corrosion and underwater, which can solve the working problems in the underwater environment. For more information please contact us.
Features
- Waterproof & dust proof, IP68 protection level optional
- Anti-corrosion stainless steel sell
- Maximum 1-96 power & signal channels
Applications
- Marine equipment
- Filling machine
- Boat or Ship
- Drilling platform
- Undersea robot
Optional
- Circuits, Voltage, Current
- Shape & dimension
- Contact / Housing Materials
- Protection grade
- Working speed
Specification
|
ACN22-04P-06S-IP67
|
Specification |
| Current & Circuits |
4circuits * 6A; 6 circuits * 2A |
| Rating Voltage |
0-240VAC/VDC |
| Dielectric strength |
≥500VAC@50Hz |
| Isolation resistance |
≥500MΩ@500VDC |
| Contact resistance |
≤10mΩ (50rpm) |
| Contact material |
Precious Metal |
| Housing material |
Aluminum alloy |
| Working temperature |
-20°C~+80°C |
| Working humidity |
60 %RH |
| IP protection grade |
IP67 |
| Operating speed |
0~250rpm |
| Outer diameter |
Ø22mm |
| Lead wire size |
AWG 20# 26# Wire Teflon® UL |
| Lead wire length |
Rotor : 250±5 mm; Stator: 250±5 mm |
Outline Drawing
