4 Circuits Signal Mini Slip Ring Capsule With Engineering Plastic Material
  • 4 Circuits Signal Mini Slip Ring Capsule With Engineering Plastic Material
  • 4 Circuits Signal Mini Slip Ring Capsule With Engineering Plastic Material
  • 4 Circuits Signal Mini Slip Ring Capsule With Engineering Plastic Material
  • 4 Circuits Signal Mini Slip Ring Capsule With Engineering Plastic Material

4 Circuits Signal Mini Slip Ring Capsule With Engineering Plastic Material

Place of Origin China
Brand Name CENO
Certification CE,RoHS,UL,ISO9001
Model Number ACN22-04S
Product Details
Current & Circuits:
4 Circuits * Signal
Rating Voltage:
12VAC/VDC
Dielectric Strength:
≥500VAC@50Hz
Isolation Resistance:
≥100MΩ@500VDC
Contact Resistance:
≤15mΩ (50rpm)
Contact Material:
Precious Metal
Housing Material:
Engineering Plastic
Working Temperature:
-20°C~+80°C
Working Humidity:
60 %RH
IP Protection Grade:
IP51
Operating Speed:
0~300rpm
Outer Diameter:
Ø22mm
Lead Wire Size:
AWG 26# Wire Teflon® UL
Lead Wire Length:
Rotor: 250±5 Mm; Stator: 250±10 Mm
Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
Carton
Delivery Time
Off the shelf
Payment Terms
T/T,Paypal,Western Union, L/C
Supply Ability
10000pcs month
Product Description

4 Circuits Signal Mini Slip Ring Capsule With Engineering Plastic Material

ACN22-04S is CENO Miniature capsule slip ring with 4 circuits signal for small smart devices, such as the high speed dome camera, children intelligent toys, stage light or drones etc. CENO miniature capsule slip ring features the domestic leading military technology, high design accuracy to ensure long service life and high reliable operation. Especial suit the small rotating system and transmit weak control signal or data. For more information please contact CENO expert.





Features

u Small compact structure

u Military grade surface treatment

u Low electrical noise & low torque

u Can integrate various signal data

u Install easy & Free maintenance



Applications

u Drones

u Radar antenna

u Video monitoring

u Traffic system

u Robot



Optional

u Circuit, Voltage, Current

u Integrate signal / data

u Contact / Housing Materials

u Shape and Dimensions

Working speed













Specification

ACN22-04S

Specification
Current & Circuits 4 circuits * Signal
Rating Voltage 0-12VAC/VDC
Dielectric strength ≥500VAC@50Hz
Isolation resistance ≥100MΩ@500VDC
Contact resistance ≤15mΩ (50rpm)
Contact material Precious Metal
Housing material Engineering Plastic
Working temperature -20°C~+80°C
Working humidity 60 %RH
IP protection grade IP51
Operating speed 0~300rpm
Outer diameter Ø22mm
Lead wire size AWG 26# Wire Teflon® UL
Lead wire length Rotor: 250±5 mm; Stator: 250±10 mm









Outline drawing

4 Circuits Signal Mini Slip Ring Capsule With Engineering Plastic Material 0















Support and Services:




Capsule Slip Ring Technical Support and Service

We provide technical support and service for our Capsule Slip Ring products. Our team of experts is available to assist you with any questions you may have about the product, its installation, its use and maintenance. We also offer troubleshooting and repair services if the product requires it. If you need to replace any parts of the product, we can provide them to you quickly and at a competitive price.

We also provide regular maintenance and inspection services for our Capsule Slip Ring products. This helps to ensure that the product is functioning properly and that it is in good condition. We also provide warranty coverage for our products, so you can rest assured that your purchase is protected.

Our customer service team is available to answer any questions you may have about our Capsule Slip Ring products. We are dedicated to providing the best possible support and service for our customers, and we look forward to hearing from you.



FAQ:

Q1. What is CENO Capsule Slip Ring?
A1. CENO Capsule Slip Ring, model number CCN-10J, is a rotary electrical connector, which can transmit power and signal from a stationary structure to a rotating one.
Q2.Where is CENO Capsule Slip Ring made?
A2. CENO Capsule Slip Ring is made in China.
Q3.What certifications do CENO Capsule Slip Ring have?
A3. CENO Capsule Slip Ring is certified by CE,RoHS,UL,ISO9001.
Q4.What is the minimum order quantity of CENO Capsule Slip Ring?
A4. The minimum order quantity of CENO Capsule Slip Ring is 1.
Q5.What is the delivery time of CENO Capsule Slip Ring?
A5. CENO Capsule Slip Ring is off the shelf and can be delivered quickly.
