| Place of Origin: | China |
| Brand Name: | CENO |
| Certification: | CE,RoHS,ISO9001,UL |
| Model Number: | BHCN-10P-20P3-02P2-09S |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cartons/As request |
| Delivery Time: | 1 weeks |
| Payment Terms: | T/T,Paypal, Western Union |
| Supply Ability: | 1000pcs per month |
| Circuit: | 3*550A(690VAC),3*80A(230VAC),3*50A(480VAC), 20*15A,2*10A,9*signal | Rating Voltage: | 690VAC/480VAC/230VAC/24VAC |
|---|---|---|---|
| Operating Speed: | 0-1rpm | Contact Material: | Copper Graphite，silver-coated Brush |
| Insulation Resistance: | 500MΩ@500VDC,300MΩ@100VDC | Protection Grade: | IP56 |
| High Light: | collector slip ring,cable reel slip ring |
||
690VAC Carbon Brush Slip Ring Safely Current Carrying Capacity
CENO's carbon Brush slip ring is also named as large current collector or high power slip ring, which could transmit the current at lease on 100A or above. It widely be used in ship machinery, engineering machinery, port machinery, offshore crane, cable reel, propeller,as well as drilling platform.
Features
Applications
Optional
Specification
| Parameter | |||
| Current |
3*550A(690VAC),3*80A(230VAC),3*50A(480VAC), 20*15A,2*10A,9*signal |
Protection grade | IP56 |
| Rating voltage | 690VAC/480VAC/230VAC/24VAC | Working temperature | -10℃~+55℃ |
| Resistance insulation | 500MΩ@500VDC,300MΩ@100VDC | Working Humidity | ＜90%RH |
| Dielectric strength | ≥1000VAC@60Hz | Working rotating | 0~1rpm |
| Resistance fluctuation | ≤70mΩ | Contact material | Copper graphite,silver-coated brush |
Outline drawing
Why with CENO
CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.
Certification
ISO9001,CE,RoHS,UL,Explosion-proof
CENO Advantage
Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.
Service CENO provides
24 hours,7days consultant service.
Mass and customized production.
Solution offerring for 360° rotation system.
Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
