| Place of Origin: | China |
| Brand Name: | CENO |
| Certification: | CE,RoHS,ISO9001,UL |
| Model Number: | ECN038-04P2-02EG-IP64 |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton/As request |
| Delivery Time: | 1 week |
| Payment Terms: | T/T,Paypal, Western Union |
| Supply Ability: | 500pcs per month |
| Current & Circuits: | 4circuits*10A, 2channel*gigabit Ethernet | Rating Voltage: | 0~220 VAC/VDC |
|---|---|---|---|
| Dielectric Strength: | ≥1000VAC@50Hz; ≥300VAC@50Hz | Isolation Resistance: | ≥500MΩ@500VDC; ≥100MΩ@100VDC |
| Operating Speed: | 0~60rpm | Contact Material: | Precious Metal / Gold To Gold |
| Housing Material: | Aluminum Alloy | Lead Wire Size: | AWG17# Tin Coated Teflon®UL Cat5e Unshielded Twisted Wire |
| Lead Wire Length: | Rotor : 1000mm Stator : 1000mm | Working Temperaturediameter: | -20°C~+60°C |
| Working Humidity: | 60%(20°C) | IP Protection Grade: | IP64 |
| Installation Way: | Rotor Side Fixed On The Main Shaft With Screws | ||
| High Light: | 2 Channel Gigabit Ethernet Slip Ring,Precious Metal Gigabit Ethernet Slip Ring,IP64 Integrated Slip Ring |
||
2 Channel Gigabit Ethernet Integrated Slip Ring For Industry Application
ECN038-04P2-02EG-IP64 is an integrated through hole slip ring combined with 4 circuits for 10A and 2 channels for gigabit Ethernet signal from CENO Electronics. The protection grade is IP64 and can be up to IP68 is optional as different application environments. It can transmit 100M and 1000M Ethernet signal, can mix multi channel various signal and currents, and no packet loss, non string code and ultra-long distance transmission in CENO Ethernet series products. Apply to various harsh environments such as high/ low temperature environment, outdoors or strong shock environment where need communication system.
Features
Integrated structure design for easy install and stable working
Applications
Optional
Specification
|
ECN038-04P2-02EG-IP64 |
Specification |
| Current & Circuits | 4circuits*10A, 2channel*gigabit Ethernet |
| Rating Voltage | 0~220 VAC/VDC |
| Dielectric strength | ≥1000VAC@50Hz; ≥300VAC@50Hz |
| Isolation resistance | ≥500MΩ@500VDC; ≥100MΩ@100VDC |
| Electrical noise | ≤70mΩ (50rpm) |
| Operating speed | 0~60rpm |
| Contact material | Precious metal / Gold to Gold |
| Housing material | Aluminum alloy |
| Working temperature | -20°C~+60°C |
| Working humidity | 60% |
| IP protection grade | IP64 |
| Through hole size | Ø38.1mm |
| Lead wire size |
AWG17# Tin coated Teflon®UL Cat5e Unshielded twisted wire |
| Lead wire length |
Rotor : 1000mm Stator : 1000mm |
| Installation | Rotor side fixed on the main shaft with screws |
Outline drawing
|
Application
|
Why with CENO
CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.
Certification
ISO9001,CE,RoHS,UL,Explosion-proof
CENO Advantage
Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.
Service CENO provides
24 hours,7days consultant service.
Mass and customized production.
Solution offerring for 360° rotation system.
Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
