| Place of Origin: | China |
| Brand Name: | CENO |
| Certification: | CE,RoHS,ISO9001,UL |
| Model Number: | ECN038-10P1-01EG |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton/As request |
| Delivery Time: | 1 week |
| Payment Terms: | T/T,Paypal, Western Union |
| Supply Ability: | 500pcs per month |
| Current & Circuits: | 10circuits*5A, 1 Circuits*5A, 1channel*1000M Ethernet | Rating Voltage: | 0~380 VAC/VDC |
|---|---|---|---|
| Dielectric Strength: | ≥1000VAC@50Hz; ≥300VAC@50Hz | Isolation Resistance: | ≥500MΩ@500VDC; ≥100MΩ@100VDC |
| Operating Speed: | 0~300rpm | Contact Material: | Precious Metal |
| Housing Material: | Aluminum Alloy | Lead Wire Size: | AWG17# Tin Coated Teflon®UL Cat5e Unshielded Twisted Wire |
| Lead Wire Length: | Rotor : 2000mm Stator : 5500mm | Working Temperaturediameter: | -20°C~+60°C |
| Working Humidity: | 60%(20°C) | IP Protection Grade: | IP51 |
| Installation Way: | Fix Up Stator Side With Anti-rotation Tab Shaft Drives Rotor Running | ||
| High Light: | 1000M Gigabit Ethernet Slip Ring,Integrated Slip Ring 300rpm,Precious Metal Integrated Slip Ring |
||
ECN038-10P1-01EG is an Gigabit Ethernet slip ring with hollow shaft and 38.1mm inner diameter from CENO Electronics. There are 10 circuits for 5A, 1 circuits for 5A and 1 channel for 1000M Ethernet, the current, circuits & Signals are optional and the multi-point brush contact material ensure long life. The integrated structure with through hole and anti-rotation tabs designs for easy installation. The IP grade can be customized as different application or operating environment. Often apply to the Communication system, automation equipment, Filling machinery, and high low temperature environment.
Features
Applications
Optional
Specification
|
ECN038-10P1-01EG |
Specification |
| Current & Circuits | 10circuits*5A, 1 circuits*5A, 1channel*1000M Ethernet |
| Rating Voltage | 0~380VAC/VDC |
| Dielectric strength | ≥1000VAC@50Hz; ≥300VAC@50Hz |
| Isolation resistance | ≥500MΩ@500VDC; ≥100MΩ@300VDC |
| Electrical noise | ≤30mΩ (50rpm) |
| Operating speed | 0~300rpm |
| Contact material | Precious metal |
| Housing material | Aluminum alloy |
| Working temperature | -20°C~+60°C |
| Working humidity | 60% |
| IP protection grade | IP51 |
| Through hole size | Ø38.1mm |
| Lead wire size |
AWG17# Tin coated Teflon®UL Cat5e Unshielded twisted wire |
| Lead wire length |
Rotor : 2000mm Stator : 5500mm |
| Installation | Fix up stator side with anti-rotation tab shaft drives rotor running |
Outline drawing
|
Application
|
Why with CENO
CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.
Certification
ISO9001,CE,RoHS,UL,Explosion-proof
CENO Advantage
Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.
Service CENO provides
24 hours,7days consultant service.
Mass and customized production.
Solution offerring for 360° rotation system.
Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
