| Place of Origin: | China |
| Brand Name: | CENO |
| Certification: | CE,RoHS,ISO9001 |
| Model Number: | ECN000-02P3-01F |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard |
| Delivery Time: | 1 week |
| Payment Terms: | T/T,Paypal,Western Union |
| Supply Ability: | 500pcs per month |
| Channel Number: | 2 | Wave Length: | 1310-1550nm |
|---|---|---|---|
| Speed: | 1000rpm Max | Housing Material: | Aluminum Alloy |
| Sealing Grade: | IP51 | Working Temperature: | -20 To 60℃ |
| Fiber Type: | SM (9/125) | ||
| High Light: | Fiber Optic Rotary Joint 35mm OD,IP51 Fiber Optic Rotary Joint,Aluminum Housing Fiber Optic Rotary Joint |
||
Power + Fiber Optic Rotary Joint 35mm OD Aluminum Alloy Housing Material
Fiber Optic Rotary Joints are to optical signals what electrical slip rings are to electrical signals, a means to pass signals across rotating interfaces, particularly when transmitting large amounts of data.
Specification
| ECN000-02P3-01F | Specification |
| Circuit & Current | 2 circuits* 12A |
| Rating Voltage | 0~400VDC |
| Fiber type | SM (9/125) |
| Connector type | SC(Female)/SC(Female) |
| Wave length | 1310~1550nm |
| Insertion loss,max | 2.5dB |
| Insertion loss WOW,max | 0.5dB |
| Working temperature | -20~+60℃ |
| Working speed | 0~1000rpm |
| Contact material | Precious Metal |
| Housing material | Aluminum Alloy |
| Protection grade | IP51 |
Optional
Circuit number
Fiber channel
Connector type
Working speed
Applications
Radio locator
Machine handy
Robot
Aeronautical applications
Outline drawing
Why with CENO
CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.
Certification
ISO9001,CE,RoHS,UL,Explosion-proof
CENO Advantage
Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.
Service CENO provides
24 hours,7days consultant service.
Mass and customized production.
Solution offerring for 360° rotation system.
Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
