ID 165mm Through Hole Slip Ring With Electrical Collector And RS485
  • ID 165mm Through Hole Slip Ring With Electrical Collector And RS485
  • ID 165mm Through Hole Slip Ring With Electrical Collector And RS485
  • ID 165mm Through Hole Slip Ring With Electrical Collector And RS485
  • ID 165mm Through Hole Slip Ring With Electrical Collector And RS485
ID 165mm Through Hole Slip Ring With Electrical Collector And RS485

ID 165mm Through Hole Slip Ring With Electrical Collector And RS485

Place of Origin China
Brand Name CENO
Certification CE,RoHS,ISO9001,UL
Model Number ECN165-04P2-06P1-02S
Product Details
Circuits & Current:
4*10A; 6*5A; 1Group*RS485
Through Bore Size:
165mm
Protection Grade:
IP51
Working Speed:
0~100rpm
Contact Material:
Precious Metal
Housing Material:
Stainless Steel
Rating Voltage:
0~220VAC/VDC
Dielectric Strength:
≥500VAC@50Hz
Isolation Resistance:
≥100MΩ@300VDC
Contact Resistance:
30mΩ (50rpm)
Working Temperature:
-30°C~+60°C
Working Humidity:
60 %RH
Highlight:

Electrical Collector Through Hole Slip Ring

,

ID 165mm Through Hole Slip Ring

,

RS485 Through Bore Slip Ring

Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
Negotiable
Packaging Details
Carton/As request
Delivery Time
1 week
Payment Terms
T/T,Paypal, Western Union
Supply Ability
500pcs per month
Product Description

Through Hole Slip Ring With ID165mm Electrical Collector And RS485



ECN165-04P2-06P1-02S is CENO’s new Through Hole Slip Ring compatible with 10 circuits for electrical power signal and 1 group for RS485 that is a common serial port for industrial bus communication, which can support multi-point and two-way communication functions, has a long communication distance, strong anti-interference ability, and improves the reliability of data transmission in the entire network. Through Hole Slip Ring is also called Through Bore Slip Ring or Hollow Shaft Slip Ring, the Inner diameter is optional from 3mm to 2000mm. Due to it’s economical and working stable often apply to various harsh environments. For more information about CENO’s slip ring, please contact us.







Features

  • Large size Inner Diameter and economical can be customized
  • Can integrated various signals as USB, Profibus, HDMI etc.
  • Install easily & transmit stably



Applications

  • Industrial automation system
  • Harsh environments
  • Electrical crane
  • Mountain areas
  • Medical equipment



Optional

  • Circuits and Current
  • Boundary Structure
  • Materials
  • IP Grade
  • Working conditions






Specification

ECN165-04P2-06P1-02S

 Specification
Current & Circuits 4 circuit*10A; 6circuit*5A; 1Group*RS485
Rating Voltage

0~220VAC/VDC
Dielectric strength ≥500VAC@50Hz
Isolation resistance ≥100MΩ@300VDC
Contact resistance 30mΩ (50rpm)
Contact material Precious Metal
Housing material Stainless steel
Working temperature -30°C~+60°C
Working humidity 60 %RH
IP protection grade IP51
Operating speed 0~100rpm
Lead wire size

AW17# 22# Tin Coated Wire Teflon® UL

Two-core twisted shielded wire

Lead wire length

Rotor : 300mm

Stator : 300mm
Inner Diameter Ø165mm
Rotation way Fix rotor side on rotation shaft with screws







Outline Drawing

ID 165mm Through Hole Slip Ring With Electrical Collector And RS485 0

















Why with CENO

CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.
ID 165mm Through Hole Slip Ring With Electrical Collector And RS485 1

Certification
ISO9001,CE,RoHS,UL,Explosion-proof
ID 165mm Through Hole Slip Ring With Electrical Collector And RS485 2

CENO Advantage
Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.

Service CENO provides
24 hours,7days consultant service.
Mass and customized production.
Solution offerring for 360° rotation system.


Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
