Through hole slip ring with inner bore 55mm for intelligence equipment
ECN055-02S is CENO classic and high economical through hole slip ring with long service life for the intelligent equipment. often called rotary electrical interface, power slip ring or electrical rotary joint. CENO slip ring features advanced fiber brush, multi-point contact and low friction. Due to high stable performance, CENO through hole slip rings popular used in the situations where 360º continuous rotation requires guaranteed power and uninterrupted signals. For more information please contact us.
Specification
|
ECN055-02S
|
Specification |
| Current & Circuits |
2 circuits signals |
| Rating Voltage |
0-12VAC/VDC |
| Dielectric strength |
≥300VAC@50Hz |
| Isolation resistance |
≥100MΩ@100VDC |
| Contact resistance |
≤30mΩ (50rpm) |
| Contact material |
Precious Metal |
| Housing material |
Aluminum alloy |
| Working temperature |
-20°C~+60°C |
| Working humidity |
60 %RH |
| IP protection grade |
IP40 |
| Operating speed |
0~100rpm |
| Inner diameter |
Ø55mm |
| Lead wire size & length |
Customized |
Features
- Long life with anti-corrosion
- Excellent electrical performance and electromagnetic interference
- Through hole 3 -1000mm option
- Install easy & Free maintenance
Applications
- Automatic machine
- Communication devices
- Aviation field
- Intelligent robot
- Military field
Optional
- Circuit, Voltage, Current
- Inner / Outer diameters
- Contact / Housing Materials
- Protection grade
- Working speed & temperature
Outline drawing
Our Service
1. Reply inquiry in 24 hours.
2. Please kindly inform us which items you are interested & the reasonable price will be provided you upon receipt of your new inquiry ASAP.
3. Answer your question detailed.
4. Solved the problem with you during using our products.
5. Samples will be offered to you for our future cooperation.
FAQ
1. What do we do?
We focus on developing, designing, manufacturing high quality sliprings, and offer various solutions for rotating systems.
2. How long have we been in the business?
CENO established slip rings business since 2009. We have thousands of customers accepted our products or services.
3. What is a slip ring?
A slip ring is an electromechanical device that allows the transmission of power and electrical signals from a stationary to a rotating structure. A slip ring can be used in any electromechanical system that requires rotation while transmitting power or signals. It can improve mechanical performance, simplify system operation and eliminate damage-prone wires dangling from movable joints.
4. How do I choose a slip ring?
Proper selection of a slip ring solution requires details about your application’s operating parameters including total circuits, voltage and amps per circuit, operating speed, and mounting type. A good place to start your search is with our standard slip rings. If you are confident that a custom / modified solution is most likely required or need assistance in your selection, contact us to Get Started.
5. Do you offer custom slip rings?
Yes, if you are confident that a custom / modified solution is most likely required or need assistance in your selection, contact us to Get Started. Our engineers will come up with perfect solution for your needs.
